Specifications |
|
Type |
: General Purpose
Design : F-PVC/90/0/Tp |
Thickness |
: 0.125 ±
0.025mm |
Tensile
Strength |
: 150 N/10mm
Width per mm thickness (min) |
Adhesion
to Steel |
: 1.6 / 10mm width
(min) |
Adhesion
to Backing |
: 1.3 / 10mm width
(min) |
Electric
Strength at Room Temperature |
: 40KV/ mm thickness
(mim) |
Electric
Strength after Humid Conditioning |
: 35KV/ mm thickness
(mim) |
Flammability |
: Self Extinguishing |
Electrolystic
Corrosion |
: Within Permissible
Degrees Of Corrosion. :
As Specified in IS : 8516 |
Insulation
Resistance after 24 Hours
Exposure at 27° ± 2°C and
97° ± 2° Relative HumidityType |
: 1011OHMS (min) |
Stability
to Accelerated Ageing |
: No deterioration
or change in properties |
